Under Oven Drawer Set

• Fits beneath a single built-in oven, utilising the bottom of the cabinet and the plinth
• For 600 mm cabinet width
• Runners are completely concealed beneath the drawer base and cannot be seen when fully extended
• Runners are for 19 mm board thickness, plastic spacers are included for other board thicknesses
• Set consists of:
- Drawer (1 pc)
Aluminium/grey coloured plastic, designed to accept 8 mm chipboard base if required
- Dynamic runners (1 pair)
Galvanised steel, full extension, self closing runners, load capacity 30 kg
- Drawer front fixing brackets (2 pcs)
White plastic, screw fixed to drawer front and locked in place by turning lever
- Plinth fixing brackets (2 pcs)
White plastic, with 45 mm adjustment
- Runner fixing clip (2 pcs)
White plastic. To be fitted within drawer side either in 15/16 or 18/19 mm position
- Spacers (4 pcs)
White plastic, 2 each 1 and 3 mm thickness included for use with runners where board thickness are other than 19 mm
- Plinth feet (4 pcs)
Includes adaptors to fit underneath the cabinet sides
• A deep drawer version can also be created when used in conjunction with railing 545.39.230 shown in Related Products
